Chemical Balance
Features :
- Large LCD display for easy view.
- Standard RS 232 interface.
- Parts Counting & percent weighing.
- Below balance weighty facility.
- Die cast aluminum design for long term stability & accurate result
- Various weighing units like ct, gm, oz, dwt, mom, GN.
- ISO-GLP compliance printouts (optional)
Specifications:
| SPECIFICATION | CTA 200 | CTA 300 | CTA 600 |
| Capacity | 200g | 300g | 600g |
| Readability | 0.01g | 0.01g | 0.01g |
| Linearity | +0.01 | +0.01 | +0.02 |
| Pan Size | 110mm | ||
| Display | Liquid Crystal Display 13 mm Height | ||
| Weight | 1.8Kg | ||
| Dimension | 190 (W)x200 (D)x80 (H)mm | ||
| Power | 9V/500mA AC/DC Adaptorm | ||
| Environment | 0° C -40° C (32° F-104° F) RH < 85% | ||
Electronic Top Loading Balance
Features:
- High contrast LCD displays weight and text messages to guide you every step of the way
- AC powered or battery operated so you can take your lab with you
- Large stainless steel weighing pans
- Windshield protects pan and blocks air currents for stable results
- Standard RS 232 interface
- Parts Counting and percent weighing.
- Animals Weighing
- Below balance weighing facility
- Die cast aluminum design for long term stability and accurate result
- Density determination for Solid and liquid
- Various weighing units like ct, gm, oz, dwt, mom, GN
Specifications:
| Capacity x Readability (carats) | 605 x 0.001 ct |
| Capacity(g) x Readability (mg) | 121 g x 0.2 mg |
| Reproducibility (std deviation) | – |
| carats (ct) | ± 0.001 ct |
| milligrams (mg) | ± 0.2 mg |
| Linearity | – |
| carats (ct) | ± 0.002 ct |
| milligrams (mg) | ± 0.4 mg |
| Response Time (average) | 3 seconds |
| Tara Range | FULL to Capacity |
| Selectable Weight Units | g, ct, lb, oz, ozt, tlh, tls, tlt, Gn, dwt, mg, parts/lb, tlc, mom, K, tol, bat, MS |
| Selectable Application Programs | Mass unit conversion by toggling, tare memory, net total, weighing in percent, counting, averaging |
| Display | LCD |
| Allowable Ambient Operating Temperature | 5° C to 40 ° C (41° F to 104° F) 85% RH or less |
| Sensitivity Drift (10° – 30°C/50°F-86°F) | ± 2 ppm / °C |
| External Calibration | 100g |
| Pan Size | ø90 mm / 3.5 in (standard round pan) |
| Draft Shield Chamber Height (from pan to top of glass door) | 133 mm / 5.23 in |
| Dimensions (entire balance) W x D x H | 200 x 270 x 233 mm 7.9 x 10.6 x 9.2 in |
| Built-in RS-232 Interface | YES – RS-232 interface is standard but the RS-232 cable is optional |
| Weighing Below | Not Available. Common applications for weighing below the balance include density determination. |
| AC Power Source | AC Adapter 120 VAC |
| Power Consumption | Approx. 16VA (supplied by AC adapter) |
| Standard Equipment | 120V AC Adapter, Stainless steel weighing pan, 100g external cal mass |
Physical Balance
Features:
- Liquid Crystal Display
- High Internal Resolution
- Grams & Carats
- Digital Auto Calibration
- Sleep mode for extended battery life (Optional)
- Low battery indication
- Overload protection
Specifications:
| SPECIFICATION | GTA 200 | GTA 300 | GTA 600 |
| Capacity | 200g | 300g | 600g |
| Readability | 0.01g | 0.01g | 0.01g |
| Linearity | +0.01 | +0.01 | +0.02 |
| Pan Size | 110mm | ||
| Display | Liquid Crystal Display 13 mm Height | ||
| Weight | 1.8Kg | ||
| Dimension | 190 (W)x200 (D)x80 (H)mm | ||
| Power | 9V/500mA AC/DC Adaptorm | ||
| Environment | 0° C -40° C (32° F-104° F) RH < 85% | ||
